A-SERIES
EXTERIOR TRIM

HEAD TRIM OPTIONS

Installation Options

Preassembled Trim Surrounds
Factory-assembled
surrounds install in
seconds on A-Series
windows with optional
factory-applied exterior
trim flange.
Precut Kits
Knock down kits include Decorative Drip Cap 2" (51) Cornice 3 5 /8" (92) Cornice
precut and predrilled Shown with 3 1 /2" Flat. Forest Green Shown with 3 1 /2" Flat. Prairie Grass Shown with 3 1 /2" Flat. White trim
trim with Sandtone window.
trim with Sandtone window.
with Sandtone window.
trim with all the
necessary components
for on-site assembly SILL OPTIONS
for windows and patio
doors up to 12' (3658) Mix and match trim to create a variety of combinations. Not all sill options are shown.
in width or height.
Individual Trim Components Exterior Trim
13' (3962) factory-
finished trim lineals,
end caps, corner
keys, fasteners,
metal drip caps and
field attachment
strips allow for field Brick Mould 3 1 /2" (89) or 4 1 /2" (114) Flat 3 1 /2" (89) 4 1 /2" (114) Flat
fabrication and assembly. Shown with extended sill nose. Shown with extended sill nose. Terratone Shown with 3 1 /2" Flat. White trim
Terratone trim with White window. trim with Red Rock window. with White window.
TRIM COMBINATIONS
ACCESSORIES Sold Separately
®
Fibrex Trim Board 3 1 /2" (89) Flat or 4 1 /2" (114) Flat Brick Mould

1
Andersen offers a 3 ⁄2" (89) wide by
3 ⁄4" (19) thick cellular Fibrex trim board in Brick mould can be used on all four sides
10' (3048) lengths. Available in the same or with a flush or extended sill nose.
11 colors as the exterior trim system, this
solid trim board can be ripped to size and Sill Nose
can be fastened using nails or screws.
Coil Stock
Flat trim can be used on all four sides either flush
or extended at the head or sill. Combine 3 ⁄2" (89)
1
and 4 ⁄2" (114) flat trim or use with a flush or
1
extended sill nose.
Sill nose can be used with flat trim or brick mould.
Decorative Drip Cap and Cornices It can be applied flush or extended at the sill.
Factory-finished in any of our 11 exterior
trim colors, our aluminum coil stock allows
you to form your own profiles in the field. Not all trim options and/or combinations are shown.
Made from .018-thick aluminum, coil stock Contact your Andersen supplier for more information.
is available in 24" (610) x 50' (15240)
rolls. Color-matched stainless steel trim
nails are also available and can be ordered
in 1 lb or .454 kg boxes.
Decorative drip cap or cornices can be
used above flat trim at the head. Dimensions in parentheses are in millimeters.
Printing limitations prevent exact duplication of colors.
See your Andersen supplier for actual color samples.
